Aluminium Propellers for Yamaha Outboards


Buying Options

Quantity Image Name Price
Yamaha - 2HP, Diameter 7 ¼", Pitch 5" Yamaha - 2HP, Diameter 7 ¼", Pitch 5"
Pin Drive - OEM Part equiv: 6F8-45942-01-EL
$25.00
In stock
Yamaha - 2.5HP, Diameter 7 ¼", Pitch 6" Yamaha - 2.5HP, Diameter 7 ¼", Pitch 6"
9 splines - OEM Part equiv: 6E0-45949-00-EL
$35.00
In stock
Yamaha - 4/5HP, Diameter 7 ½", Pitch 7" Yamaha - 4/5HP, Diameter 7 ½", Pitch 7"
9 splines - OEM Part equiv: 6E0-45943-01-EL
$39.00
In stock
Yamaha - 9.9/15HP, Diameter 9 ¼", Pitch 8" Yamaha - 9.9/15HP, Diameter 9 ¼", Pitch 8"
8 splines - OEM equiv: 683-45947-00-EL/63V-45947-00-EL
$65.00
In stock
Yamaha - 9.9/15HP, Diameter 9 ¼", Pitch 9" Yamaha - 9.9/15HP, Diameter 9 ¼", Pitch 9"
8 splines - OEM equiv: 683-45945-00-EL/63V-45945-10-EL
$65.00
In stock
Yamaha - 9.9/15HP, Diameter 9 ¼", Pitch 10" Yamaha - 9.9/15HP, Diameter 9 ¼", Pitch 10"
8 splines - OEM Part equiv: 63V-45945-00-EL
$65.00
In stock
Yamaha - 9.9/15HP, Diameter 9 ¼", Pitch 11" Yamaha - 9.9/15HP, Diameter 9 ¼", Pitch 11"
8 splines - OEM Part equiv: 63V-45943-00-EL
$65.00
In stock
Yamaha 20/30HP, Diameter 9 ⅞", Pitch 10 ½" Yamaha 20/30HP, Diameter 9 ⅞", Pitch 10 ½"
10 splines - OEM Part equiv: 664-45945-00-EL
$75.00
In stock
Yamaha 20/30HP, Diameter 9 ⅞", Pitch 12" Yamaha 20/30HP, Diameter 9 ⅞", Pitch 12"
10 splines - OEM Part equiv: 664-45954-01-EL
$75.00
In stock
Yamaha 25/60HP, Diameter 11 ⅛", Pitch 13" Yamaha 25/60HP, Diameter 11 ⅛", Pitch 13"
13 splines - OEM Part equiv: 663-45945-02-EL
$85.00
In stock
Yamaha 25/60HP, Diameter 11 ⅜", Pitch 12" Yamaha 25/60HP, Diameter 11 ⅜", Pitch 12"
13 splines - OEM Part equiv: 663-45952-02-EL
$95.00
In stock
Yamaha 40/50HP, Diameter 11⅝", Pitch 11" Yamaha 40/50HP, Diameter 11⅝", Pitch 11"
13 splines - OEM Part equiv: 663-45947-02-EL
$105.00
In stock
Yamaha 60/130HP, Diameter 13", Pitch 19" Yamaha 60/130HP, Diameter 13", Pitch 19"
15 splines - OEM Part equiv: 6E5-45941-00-EL
$140.00
In stock
Yamaha 60-130HP, Diameter 14", Pitch 11" Yamaha 60-130HP, Diameter 14", Pitch 11"
15 splines - OEM Part equiv: 6E5-45954-00-EL
$190.00
In stock
Yamaha 60/130HP, Diameter 14", Pitch 19" Yamaha 60/130HP, Diameter 14", Pitch 19"
15 splines - OEM Part equiv: 6G5-45945-01-98
$220.00
In stock

These low cost, high quality PowerWing, lightweight propellers for Yamaha outboard motors are vacuum casted in aluminium to improve tensile strength and reduce possibility of gas bubbles. The propeller is then threefold powder coated for maximum protection and appearance.

All parts for a PowerWing propeller are made in the PowerWing factory using proprietory moulds and machinery.

PowerWing your guarantee of quality.

Each propeller has a rubber hub or inner hub bushing made of unique hard rubber, moulded to a proprietory splined brass spindle (corrosion proof coating) to keep the propeller precision-centered on the propshaft, dampen vibrations and help protect the shaft from the severe shock of striking a submerged object with the propeller.

Propeller markings indicate, for example 9 ¼  X 9:

  • The propeller diameter (in the example above 9 ¼ inches).
  • The propeller pitch. Pitch is the theoretical travel of a propeller through a mass per revolution (In the example above, 9" pitch propeller moves forward approximately 9 inches per revolution). Each increase in pitch of 1 inch equals approximately 100 RPM.

(YAMPROPAL)

SKU YAMPROPAL
Brand PowerWing
Unit Of Measure ea
