Click here to view article on installing your bilge pump. This article contains important facts you should consider prior to your purchase.
Please note, a bilge pump's sole use is for the intermittent pumping of seawater/freshwater ingress. Bilge pumps are not designed to pump chlorinated water, viscose liquids, oil or fuel.
Bilge Pumps are rated at "ZERO" head or height above outlet.
Also please note: GPH (LPH) and Maximum Head are always calculated in optimum test conditions. As a rule of thumb maximum head and GPH (LPH) should be calculated at 60% of the rated head and output. This will ensure you are covered for both the run length and head height. For example; if you want an output of 1100GPH. Then fit a 2,000GPH bilge pump. A 4 metre rated maximum head is probably only effective to 2.4 metres with a horizontal run.
SPECIFICATIONS BY MODEL (12 Volt)
|Model||LPM||Volts||Amps||Fuse (amps)||Hose Size (mm)||Base Dia (mm)||Dia inc Outlet (mm)||Height (mm)||Weight (Kgs)|
|750 GPH AUTO S6||43||12||5||5||19||83||145||103||0.47|
|750 GPH AUTO S11||43||12||5||5||19||83||166||105||0.55|
|1100 GPH AUTO S6||69||12||6||10||28.5||83||150||103||0.47|
|1100 GPH AUTO S11||69||12||5||5||28.5||83||166||103||0.55|
|1100 GPH AUTO S13||69||12||4||5||25 or 28.5||70||132||110||0.40|
|1100 GPH AUTO S14||69||12||4.2||5||19, 25 & 28.5||57||204||84||.56|
|Brand||Seaflo - Original and Genuine|
