Series 22 12V Diaphragm Pump Max Flow 5LPM @ 100PSI
Intermittant Duty
$70.00
In Stock
3 Year Warranty
Seaflo Series 22 is an intermittant duty, on demand positive displacement pump.
Series 22 pumps provide reliable performance in moderate water flow, high-pressure applications.
The 2 chamber diaphragm pump provides excellent water pressure and is capable of self-priming up to 1.8 metres. Seaflo pumps can run dry without damaging components.
These automatic demand water system pumps have a built-in pressure switch, automatically starting/stopping when the fixture is opened/closed.
They are simple to install and service.
Miniature multi outlet water pressure pump serves 1 or 2 3/8” (10 mm) outlets at any one time. This automatic demand water system pump has a built-in pressure switch, which automatically starts and stops when the fixture is opened and closed. They are easy to install, service and winterize.
Comes in Black only.
| Model | Series | Voltage | Open Flow | Shut-off Pressure | Max Draw | Control Type | Valves | Diaphragm | Ports | Wire Connections |
| （US GPM/LPM） | （PSI/BAR) | |||||||||
| SFDP1-013-100-22 | Series 22 | 12V | 1.3/5 | 100/6.9 | 6 Amps | Demand & Bypass | EPDM | Santoprene | 3/8" (10 mm) hose tail | 2-Pin/Leads |
Product Data Comparison for Seaflo Diaphragm Pumps
| Model | Volts | Amps | Fuse (amps) | LPM | PSI | Ports (inch) | Length (mm) | Width inc Base (mm) | Height (mm) | Weight (Kgs) |
| Series 22 | 12 | 6 | 9 | 5.0 | 100 | 3/8" Hose Tail | 187 | 98 | 72 | 1.10 |
| Series 33 | 12 | 8 | 10 | 11.6 | 45 | 1/2" MNPT | 202 | 130 | 123 | 1.92 |
| Series 35 | 12 | 9 | 15 | 7.0 | 80 | Quick Att | 210 | 102 | 115 | 2.34 |
| Series 42 | 12 | 6 | 10 | 9.5 | 55 | 1/2" MNPT | 230 | 125 | 111 | 1.90 |
| Series 51 | 12 | 15 | 20 | 19.0 | 60 | 1/2" MNPT | 216 | 146 | 131 | 2.48 |
(SFDP1-013-100-22)
| SKU | SFDP1-013-100-22 |
| Barcode # | 2000000007434 |
| Brand | Seaflo - Original and Genuine |
| Shipping Weight | 1.2000kg |
| Shipping Width | 0.110m |
| Shipping Height | 0.080m |
| Shipping Length | 0.210m |
| Shipping Cubic | 0.001848000m3 |
| Unit Of Measure | ea |
